Figure: NE5532 Preamplifier Circuit Diagram

The NE5532 is a popular dual operational amplifier known for its high performance and low noise characteristics. It is widely used in audio preamplifier circuits due to its excellent frequency response and stability. This diagram illustrates the basic configuration of a preamplifier using the NE5532, showing how it can be connected to amplify weak signals before they are sent to an amplifier or speaker system. Whether you're building your own audio equipment or troubleshooting an existing circuit, understanding this layout is essential for proper functionality and sound quality.
